Wood vs concrete ties

Started by Ted, May 10, 2020, 03:27:06 PM

Previous topic - Next topic

0 Members and 1 Guest are viewing this topic.

Ted

Hi everyone,

Based on the ties, am I right in saying the track in the foreground is wooden sleeper and the two rails behind are concrete?

Ref - https://www.flickr.com/photos/railpics-online/32404411357/
Just call me Ted, or Edward... or Ed.

Just not Eddie.

Layout & Updates > Midlands Coal & Freight, Late 1980's


chrism

Quote from: Ted on May 10, 2020, 03:27:06 PM
Hi everyone,

Based on the ties, am I right in saying the track in the foreground is wooden sleeper and the two rails behind are concrete?

Ref - https://www.flickr.com/photos/railpics-online/32404411357/

No, I strongly suspect that the two rails behind are steel  :P

However, I also suspect that they may be sitting on concrete sleepers.

ntpntpntp

Front track is clearly bullhead rail on wooden sleepers.

The track behind is flatbottom rail with Pandrol type clips?  Difficult to see clearly which type, but it does look suspiciously like concrete sleepers.

Found this interesting page whilst wandering round google trying to find photos of Pandrols

http://www.mmrs.co.uk/technical-articles/modern-permanent-way/
Nick.   2021 celebrating the 25th anniversary of "Königshafen" exhibition layout!
https://www.ngaugeforum.co.uk/SMFN/index.php?topic=50050.0

njee20

I agree with Nick. Bullhead with wooden sleepers in the foreground, flat bottom, probably with concrete in the background.

Ps Americans have ties, we have sleepers or bearers ;)

Ted

I thought 'ties' were the things that actually held the rail to the sleeper! Doh.
Just call me Ted, or Edward... or Ed.

Just not Eddie.

Layout & Updates > Midlands Coal & Freight, Late 1980's


Train Waiting

Quote from: ntpntpntp on May 10, 2020, 03:51:40 PM
Front track is clearly bullhead rail on wooden sleepers.

The track behind is flatbottom rail with Pandrol type clips?  Difficult to see clearly which type, but it does look suspiciously like concrete sleepers.

Found this interesting page whilst wandering round google trying to find photos of Pandrols

http://www.mmrs.co.uk/technical-articles/modern-permanent-way/

I agree with Nick.  The front line is bullhead rail in three-hole chairs on wooden sleepers.  Modellers often call these three bolt chairs but the normal fixing for these is a screw.  The lines behind certainly look like concrete sleepers and the flat-bottom rails are secured by 'Pandrol' clips.



Thank you for that interesting link, Nick.

Best wishes.

John
Please visit us at www.poppingham.com

'Why does the Disney Castle work so well?  Because it borrows from reality without ever slipping into it.'

(Acknowledgement: John Goodall Esq, Architectural Editor, 'Country Life'.)

The Table-Top Railway is an attempt to create, in British 'N' gauge,  a 'semi-scenic' railway in the old-fashioned style, reminiscent of the layouts of the 1930s to the 1950s.

For the made-up background to the railway and list of characters, please see here: https://www.ngaugeforum.co.uk/SMFN/index.php?topic=38281.msg607991#msg607991

Neil of Teesside

You can even get chaired bull-head track on concrete sleepers, not so common on the railway network but still in use on the Nene Valley Railway.
